AK-3701
LESTAR
FEATURES
BATTERY POWERED
Completely battery-powered system - no long power cords, heavy cables or generators necessary.
HEAVY-DUTY DESIGN
3.25mm electrodes can weld up to 41 pieces.
2.5mm electrodes can weld up to 85 pieces.
SAFETY & RELIABILITY
Internal lithium battery cells we are working with CATL, CATL battery cells widely used in car industry, main customer including many famous brands such as BMW, Volkswagon, Toyota and Audi. Battery power system matters a lot in battery welder, we tried many different suppliers and finally we found CATL is the best choice for our welder.
CE CERTIFICATE
AK-370 already got CE certificate, European countries marketing already under developing, also we got BSCI, ISO 9001 approval.
HOT-START & ARC FORCE
Both functions ensures easy welding and excellent welding performance.
INTELLIGENT
Battery power indicator
Under-voltage, over-heating alarm.
QUICK CHARGING
Equipped with high efficiency battery charger, charging time 3.0-3.5 hours only.
FEATURES
BATTERY POWERED
Completely battery-powered system - no long power cords, heavy cables or generators necessary.
HEAVY-DUTY DESIGN
3.25mm electrodes can weld up to 41 pieces.
2.5mm electrodes can weld up to 85 pieces.
SAFETY & RELIABILITY
Internal lithium battery cells we are working with CATL, CATL battery cells widely used in car industry, main customer including many famous brands such as BMW, Volkswagon, Toyota and Audi. Battery power system matters a lot in battery welder, we tried many different suppliers and finally we found CATL is the best choice for our welder.
CE CERTIFICATE
AK-370 already got CE certificate, European countries marketing already under developing, also we got BSCI, ISO 9001 approval.
HOT-START & ARC FORCE
Both functions ensures easy welding and excellent welding performance.
INTELLIGENT
Battery power indicator
Under-voltage, over-heating alarm.
QUICK CHARGING
Equipped with high efficiency battery charger, charging time 3.0-3.5 hours only.
Battery Specifications | |
Battery type | Ternary Lithium Ion battery cell |
Battery voltage | DC 48 V |
Battery capacity | 2400 Wh |
Battery cooling | Air (2 x automatic air fans) |
Welding Specifications | |
Output current | 10-150A |
Suitable electrode diameter | 1.6-4.0mm |
Duty Cycle | 100% @ 150A |
Pieces 2.5mm electrode | 85 pieces |
Pieces 3.2mm electrode | 41 pieces |
Charger Specifications | |
Charger voltage | AC 100-240 V 50/60 Hz |
Charger output | 54.6 V (15 A) |
Charging time | ± 3.5 hours |
Charging cycles | 1,500 (capacity > 80%) |
Working Temperatures | |
Operating temperature | -20°C up to 40°C |
Charging temperature | 0°C up to 30°C |
Storage temperature | 0°C up to 25°C |
Dimensions and Weight | |
Dimensions (L x W x H) | 460 x 210 x 350 mm |
Weight | 22.5 kg |
Other | |
Ingress protection class | IP21 (indoor) |
Warranty | 12 months or 300 charging cycles. Whichever comes first. |
Battery Specifications | |
Battery type | Ternary Lithium Ion battery cell |
Battery voltage | DC 48 V |
Battery capacity | 2400 Wh |
Battery cooling | Air (2 x automatic air fans) |
Welding Specifications | |
Output current | 10-150A |
Suitable electrode diameter | 1.6-4.0mm |
Duty Cycle | 100% @ 150A |
Pieces 2.5mm electrode | 85 pieces |
Pieces 3.2mm electrode | 41 pieces |
Charger Specifications | |
Charger voltage | AC 100-240 V 50/60 Hz |
Charger output | 54.6 V (15 A) |
Charging time | ± 3.5 hours |
Charging cycles | 1,500 (capacity > 80%) |
Working Temperatures | |
Operating temperature | -20°C up to 40°C |
Charging temperature | 0°C up to 30°C |
Storage temperature | 0°C up to 25°C |
Dimensions and Weight | |
Dimensions (L x W x H) | 460 x 210 x 350 mm |
Weight | 22.5 kg |
Other | |
Ingress protection class | IP21 (indoor) |
Warranty | 12 months or 300 charging cycles. Whichever comes first. |
Battery Charger 15A AC 110-240V
Charging Cable
Welding Connectors 35-50MM2
Instruction book
Heavy-duty earth clamp 3 meters(Optional)
Heavy-duty welding holder 5 meters(Optional)
Battery Charger 15A AC 110-240V
Charging Cable
Welding Connectors 35-50MM2
Instruction book
Heavy-duty earth clamp 3 meters(Optional)
Heavy-duty welding holder 5 meters(Optional)
No. 108, Huanglong Industrial Zone, Jinhua City, Zhejiang Province, China
